Woom OFF 5
Details
The ultralight and durable 24" mountain bike with a carbon fork, 9-speed gearing and disc brakes is designed for children aged 7 years and over.
NOTE: You won't be able to upgrade the woom OFF to an air suspension fork later on. If you think your rider would benefit from suspension, consider the OFF AIR.
Better OFF
The new 24" woom OFF 5 is bound to take your rider’s skills to the next level. Whether off-road or on, the bike combines rugged capability with ergonomics designed for growing bodies and developing skills. Stable, responsive, and equipped with high-performance components and tubeless-compatible rims and tires, the woom OFF 5 provides best-in-class value in its category. Available in black and terra-coppa, this kids’ mountain bike doesn't sacrifice form for function.
| Model | Inseam | Height |
|---|---|---|
| woom OFF 4 | 22.8" - 28.7" | 46" - 51" |
| woom OFF 5 | 27.8" - 33.7" | 50" - 57" |
| woom OFF 6 | 30.3" - 37.8" | 55" - 65" |
| woom OFF AIR 4 | 22.8" - 28.7" | 46" - 51" |
| woom OFF AIR 5 | 28.3" - 34.3" | 50" - 57" |
| woom OFF AIR 6 | 30.7" - 38.2" | 55" - 65" |
| Tire/wheel size | 24" |
|---|---|
| Handlebar height | 35" |
| Steering angle | 69° |
| Horizontal top tube length | 20.7" |
| Wheelbase | 38.2" |
| Seat tube angle | 70° |
| Minimum saddle height | 28.3" |
| Max. saddle height | 34.3" |
| Crank arm length | 5.1" |
| Handlebar adjustment | Angle +/-15°, Height +/-0.47" |
Specs
| Frame | Frame material: lightweight, high-quality 6061 T6 aluminum with butted and hydroformed tubes 24? wheels Easy-access low top tube to assist dismounting Long wheelbase and low center of gravity to aid balancing New, dropper seatpost-ready design Featuring woom-specific molded chainstay protector |
|---|---|
| Fork | Light carbon fork 1 – 1 1/8" tapered steerer tube 100 x 15 mm thru axles Post mount for disc brake |
| Wheels | Tubeless-compatible Alexrims wheelset Aluminum hubs with sealed industrial bearings Thru axles for maximum torsional strength (100 x 15 mm front and 135 x 12 mm rear) 20 G14 spokes, double-crossed spoking Aluminum nipples |
| Tires | 24 x 2.35" Schwalbe Rocket Ron with ADDIX SPEED rubber compound Quality mountain bike tires with low rolling resistance, maximum grip, good shock absorption and excellent durability Presta valves, tubeless conversion ready |
| Crankset | Lightweight, forged aluminum 5.1" (130 mm) kid-specific cranks with narrow tread (Q-factor) Narrow-wide chainring with 28 teeth in the front Cassette with 11-34 teeth in the back Flat pedals made from fiber-reinforced nylon Chromoly axle and sealed industrial ball bearings |
| Brakes | Hydraulic disc brakes by Promax Rotor diameter front/back: 160/160 mm Ergonomic brake levers designed for children's hands |
| Handlebars | Wide, ergonomically adapted and lightweight aluminum bars for more control Tapered end to fit child’s hand Sandblasted and silver anodized Width: 585 mm Rise: 20 mm |
| Tape/Grips | Child-friendly thanks to small diameter Single-clamp grip to prevent twisting Safety zone: extra rubber on palm-facing portion of grip for added comfort 100% silicone for maximum grip |
| Stem | Forged aluminum CNC-machined Handlebars attached via two clamps Rise/drop: +/-15° with flip-flop design to adjust handlebar height Length: 50 mm |
| Headset | Fully integrated 1 – 1 1/8" headset Sealed industrial bearings |
| Seatpost | 27.2 x 250 mm Anodized aluminum seatpost with insertion marks that indicate the minimum insertion depth Quick-release seatpost clamp |
| Saddle | Ergonomically designed to fit children's anatomy Streamlined mountain-bike specific saddle design Side protection to lean against walls |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN | Store SKU |
|---|---|---|---|
| Black / 24-inch | 09120083727050 | 100018-0063-8001 | 210000042387 |
| Terra Coppa / 24-inch | 09120083727067 | 100018-0063-5001 |
